The Complete Guide to Database Migrations with Liquibase

The Complete Guide to Database Migrations with Liquibase

Technology
databasespring-bootbackendguidetools
By Yuniel Acosta Pérez

Database migrations are a critical aspect of application development that’s often overlooked until it causes production issues. Liquibase provides a robust solution for versioning and managing database schema changes. In this comprehensive guide, we’ll explore how to effectively use Liquibase in Spring Boot applications.

Why Database Migrations Matter

Database migrations allow you to:

  • Version control your database schema alongside your application code
  • Maintain consistency across development, staging, and production environments
  • Collaborate effectively with team members on schema changes
  • Roll back problematic changes safely
  • Track the history of database modifications

Without proper migration management, you risk data loss, schema inconsistencies, and deployment failures.

Setting Up Liquibase with Spring Boot

1. Adding Dependencies

// build.gradle.kts
dependencies {
    implementation("org.springframework.boot:spring-boot-starter-data-jpa")
    implementation("org.liquibase:liquibase-core")
    runtimeOnly("org.postgresql:postgresql")

    // For testing
    testImplementation("org.testcontainers:postgresql")
    testImplementation("org.testcontainers:junit-jupiter")
}

2. Configuration

# application.yml
spring:
  datasource:
    url: jdbc:postgresql://localhost:5432/hatchgrid
    username: ${DB_USERNAME:hatchgrid}
    password: ${DB_PASSWORD:password}
    driver-class-name: org.postgresql.Driver

  liquibase:
    change-log: classpath:db/changelog/db.changelog-master.xml
    enabled: true
    drop-first: false
    contexts: development,test,production

  jpa:
    hibernate:
      ddl-auto: validate # Important: Don't let Hibernate manage schema
    show-sql: false
    properties:
      hibernate:
        format_sql: true
        dialect: org.hibernate.dialect.PostgreSQLDialect

3. Directory Structure

src/main/resources/
├── db/
│   └── changelog/
│       ├── db.changelog-master.xml
│       ├── changes/
│       │   ├── 001-initial-schema.xml
│       │   ├── 002-add-user-table.xml
│       │   └── 003-add-user-indexes.xml
│       └── data/
│           ├── 001-initial-data.xml
│           └── 002-test-data.xml

Creating Your First Migration

Master Changelog File

<!-- db.changelog-master.xml -->
<?xml version="1.0" encoding="UTF-8"?>
<databaseChangeLog
    xmlns="http://www.liquibase.org/xml/ns/dbchangelog"
    xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
    xsi:schemaLocation="http://www.liquibase.org/xml/ns/dbchangelog
    http://www.liquibase.org/xml/ns/dbchangelog/dbchangelog-4.20.xsd">

    <!-- Schema changes -->
    <include file="changes/001-initial-schema.xml" relativeToChangelogFile="true"/>
    <include file="changes/002-add-user-table.xml" relativeToChangelogFile="true"/>
    <include file="changes/003-add-user-indexes.xml" relativeToChangelogFile="true"/>

    <!-- Data changes (development only) -->
    <include file="data/001-initial-data.xml" relativeToChangelogFile="true" context="development"/>
    <include file="data/002-test-data.xml" relativeToChangelogFile="true" context="test"/>

</databaseChangeLog>

Initial Schema Migration

<!-- changes/001-initial-schema.xml -->
<?xml version="1.0" encoding="UTF-8"?>
<databaseChangeLog
    xmlns="http://www.liquibase.org/xml/ns/dbchangelog"
    xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
    xsi:schemaLocation="http://www.liquibase.org/xml/ns/dbchangelog
    http://www.liquibase.org/xml/ns/dbchangelog/dbchangelog-4.20.xsd">

    <changeSet id="001-create-base-tables" author="yuniel-acosta">
        <comment>Create initial database structure</comment>

        <!-- Create users table -->
        <createTable tableName="users">
            <column name="id" type="BIGSERIAL">
                <constraints primaryKey="true" nullable="false"/>
            </column>
            <column name="email" type="VARCHAR(255)">
                <constraints nullable="false" unique="true"/>
            </column>
            <column name="password_hash" type="VARCHAR(255)">
                <constraints nullable="false"/>
            </column>
            <column name="first_name" type="VARCHAR(100)">
                <constraints nullable="false"/>
            </column>
            <column name="last_name" type="VARCHAR(100)">
                <constraints nullable="false"/>
            </column>
            <column name="active" type="BOOLEAN" defaultValueBoolean="true">
                <constraints nullable="false"/>
            </column>
            <column name="created_at" type="TIMESTAMP" defaultValueComputed="CURRENT_TIMESTAMP">
                <constraints nullable="false"/>
            </column>
            <column name="updated_at" type="TIMESTAMP" defaultValueComputed="CURRENT_TIMESTAMP">
                <constraints nullable="false"/>
            </column>
        </createTable>

        <!-- Create roles table -->
        <createTable tableName="roles">
            <column name="id" type="BIGSERIAL">
                <constraints primaryKey="true" nullable="false"/>
            </column>
            <column name="name" type="VARCHAR(50)">
                <constraints nullable="false" unique="true"/>
            </column>
            <column name="description" type="TEXT"/>
            <column name="created_at" type="TIMESTAMP" defaultValueComputed="CURRENT_TIMESTAMP">
                <constraints nullable="false"/>
            </column>
        </createTable>

        <!-- Create user_roles junction table -->
        <createTable tableName="user_roles">
            <column name="user_id" type="BIGINT">
                <constraints nullable="false"/>
            </column>
            <column name="role_id" type="BIGINT">
                <constraints nullable="false"/>
            </column>
        </createTable>

        <!-- Add foreign key constraints -->
        <addForeignKeyConstraint
            baseTableName="user_roles"
            baseColumnNames="user_id"
            referencedTableName="users"
            referencedColumnNames="id"
            constraintName="fk_user_roles_user_id"
            onDelete="CASCADE"/>

        <addForeignKeyConstraint
            baseTableName="user_roles"
            baseColumnNames="role_id"
            referencedTableName="roles"
            referencedColumnNames="id"
            constraintName="fk_user_roles_role_id"
            onDelete="CASCADE"/>

        <!-- Add unique constraint on user_roles -->
        <addUniqueConstraint
            tableName="user_roles"
            columnNames="user_id, role_id"
            constraintName="uk_user_roles"/>

        <rollback>
            <dropTable tableName="user_roles"/>
            <dropTable tableName="roles"/>
            <dropTable tableName="users"/>
        </rollback>
    </changeSet>

</databaseChangeLog>

Advanced Migration Patterns

1. Adding Columns with Data Migration

<!-- changes/002-add-user-department.xml -->
<changeSet id="002-add-user-department" author="yuniel-acosta">
    <comment>Add department field to users and migrate existing data</comment>

    <!-- Add the new column -->
    <addColumn tableName="users">
        <column name="department" type="VARCHAR(100)"/>
    </addColumn>

    <!-- Set default value for existing users -->
    <update tableName="users">
        <column name="department" value="Unknown"/>
        <where>department IS NULL</where>
    </update>

    <!-- Make the column NOT NULL after setting defaults -->
    <addNotNullConstraint
        tableName="users"
        columnName="department"
        defaultNullValue="Unknown"/>

    <rollback>
        <dropColumn tableName="users" columnName="department"/>
    </rollback>
</changeSet>

2. Complex Data Transformations

<!-- changes/003-normalize-user-names.xml -->
<changeSet id="003-normalize-user-names" author="yuniel-acosta">
    <comment>Split full_name column into first_name and last_name</comment>

    <!-- Add new columns -->
    <addColumn tableName="users">
        <column name="first_name_new" type="VARCHAR(100)"/>
        <column name="last_name_new" type="VARCHAR(100)"/>
    </addColumn>

    <!-- Custom SQL for data migration -->
    <sql>
        UPDATE users
        SET
            first_name_new = SPLIT_PART(full_name, ' ', 1),
            last_name_new = CASE
                WHEN POSITION(' ' IN full_name) > 0
                THEN SUBSTRING(full_name FROM POSITION(' ' IN full_name) + 1)
                ELSE ''
            END
        WHERE full_name IS NOT NULL;
    </sql>

    <!-- Set default values for NULL cases -->
    <update tableName="users">
        <column name="first_name_new" value="Unknown"/>
        <where>first_name_new IS NULL OR first_name_new = ''</where>
    </update>

    <update tableName="users">
        <column name="last_name_new" value="User"/>
        <where>last_name_new IS NULL OR last_name_new = ''</where>
    </update>

    <!-- Drop old column and rename new ones -->
    <dropColumn tableName="users" columnName="full_name"/>

    <renameColumn
        tableName="users"
        oldColumnName="first_name_new"
        newColumnName="first_name"/>

    <renameColumn
        tableName="users"
        oldColumnName="last_name_new"
        newColumnName="last_name"/>

    <!-- Add NOT NULL constraints -->
    <addNotNullConstraint
        tableName="users"
        columnName="first_name"/>

    <addNotNullConstraint
        tableName="users"
        columnName="last_name"/>

    <rollback>
        <!-- Rollback is complex for this migration -->
        <addColumn tableName="users">
            <column name="full_name" type="VARCHAR(200)"/>
        </addColumn>

        <sql>
            UPDATE users
            SET full_name = CONCAT(first_name, ' ', last_name);
        </sql>

        <dropColumn tableName="users" columnName="first_name"/>
        <dropColumn tableName="users" columnName="last_name"/>
    </rollback>
</changeSet>

3. Creating Indexes for Performance

<!-- changes/004-add-performance-indexes.xml -->
<changeSet id="004-add-performance-indexes" author="yuniel-acosta">
    <comment>Add indexes for commonly queried columns</comment>

    <!-- Index for email lookups -->
    <createIndex indexName="idx_users_email" tableName="users">
        <column name="email"/>
    </createIndex>

    <!-- Composite index for active users by department -->
    <createIndex indexName="idx_users_active_department" tableName="users">
        <column name="active"/>
        <column name="department"/>
    </createIndex>

    <!-- Partial index for active users only -->
    <sql>
        CREATE INDEX idx_users_active_created_at
        ON users(created_at)
        WHERE active = true;
    </sql>

    <!-- Index for date range queries -->
    <createIndex indexName="idx_users_created_at" tableName="users">
        <column name="created_at"/>
    </createIndex>

    <rollback>
        <dropIndex indexName="idx_users_email" tableName="users"/>
        <dropIndex indexName="idx_users_active_department" tableName="users"/>
        <dropIndex indexName="idx_users_created_at" tableName="users"/>
        <sql>DROP INDEX IF EXISTS idx_users_active_created_at;</sql>
    </rollback>
</changeSet>

Environment-Specific Migrations

Using Contexts

<!-- Development data -->
<changeSet id="dev-001-sample-users" author="yuniel-acosta" context="development">
    <comment>Add sample users for development</comment>

    <insert tableName="users">
        <column name="email" value="admin@hatchgrid.com"/>
        <column name="password_hash" value="$2a$10$encoded.hash.here"/>
        <column name="first_name" value="Admin"/>
        <column name="last_name" value="User"/>
        <column name="department" value="IT"/>
    </insert>

    <insert tableName="users">
        <column name="email" value="developer@hatchgrid.com"/>
        <column name="password_hash" value="$2a$10$encoded.hash.here"/>
        <column name="first_name" value="Developer"/>
        <column name="last_name" value="User"/>
        <column name="department" value="Engineering"/>
    </insert>
</changeSet>

<!-- Production-only optimization -->
<changeSet id="prod-001-performance-tuning" author="yuniel-acosta" context="production">
    <comment>Production-specific performance optimizations</comment>

    <sql>
        -- Analyze tables for query planner
        ANALYZE users;
        ANALYZE roles;
        ANALYZE user_roles;

        -- Set more aggressive autovacuum for high-traffic tables
        ALTER TABLE users SET (autovacuum_vacuum_scale_factor = 0.1);
        ALTER TABLE user_roles SET (autovacuum_vacuum_scale_factor = 0.05);
    </sql>
</changeSet>

Environment Configuration

# application-development.yml
spring:
  liquibase:
    contexts: development
    drop-first: true  # Recreate database on startup

# application-production.yml
spring:
  liquibase:
    contexts: production
    drop-first: false
    test-rollback-on-update: true

Using Liquibase with Kotlin and Spring Boot

1. Configuration Class

@Configuration
@Profile("!test")
class LiquibaseConfig {

    @Bean
    @ConditionalOnProperty(name = ["spring.liquibase.enabled"], havingValue = "true", matchIfMissing = true)
    fun liquibase(dataSource: DataSource): SpringLiquibase {
        return SpringLiquibase().apply {
            this.dataSource = dataSource
            changeLog = "classpath:db/changelog/db.changelog-master.xml"
            contexts = "development,production"
            isDropFirst = false
            isShouldRun = true
        }
    }
}

2. Custom Liquibase Service

@Service
class DatabaseMigrationService(
    private val liquibase: Liquibase
) {
    private val logger = LoggerFactory.getLogger(DatabaseMigrationService::class.java)

    @EventListener(ApplicationReadyEvent::class)
    fun validateDatabaseState() {
        try {
            val unrunChangeSets = liquibase.listUnrunChangeSets(null, null)
            if (unrunChangeSets.isNotEmpty()) {
                logger.warn("Found {} unrun changesets", unrunChangeSets.size)
                unrunChangeSets.forEach { changeSet ->
                    logger.warn("Unrun changeset: {} by {}",
                        changeSet.id, changeSet.author)
                }
            } else {
                logger.info("Database schema is up to date")
            }
        } catch (e: Exception) {
            logger.error("Failed to validate database state", e)
            throw IllegalStateException("Database validation failed", e)
        }
    }

    fun generateMigrationScript(outputFile: String) {
        try {
            liquibase.update(null, FileWriter(outputFile))
            logger.info("Migration script generated: {}", outputFile)
        } catch (e: Exception) {
            logger.error("Failed to generate migration script", e)
            throw RuntimeException("Script generation failed", e)
        }
    }
}

Testing Migrations

1. Test Configuration

@TestConfiguration
class TestLiquibaseConfig {

    @Bean
    @Primary
    fun testLiquibase(@Qualifier("testDataSource") dataSource: DataSource): SpringLiquibase {
        return SpringLiquibase().apply {
            this.dataSource = dataSource
            changeLog = "classpath:db/changelog/db.changelog-master.xml"
            contexts = "test"
            isDropFirst = true
            isShouldRun = true
        }
    }
}

2. Migration Tests

@SpringBootTest
@Testcontainers
class DatabaseMigrationTest {

    @Container
    companion object {
        @JvmStatic
        val postgres = PostgreSQLContainer<Nothing>("postgres:15").apply {
            withDatabaseName("test_db")
            withUsername("test")
            withPassword("test")
        }
    }

    @Autowired
    lateinit var dataSource: DataSource

    @Test
    fun `should apply all migrations successfully`() {
        val liquibase = LiquibaseFactory().createLiquibase(
            "db/changelog/db.changelog-master.xml",
            ClassLoaderResourceAccessor(),
            JdbcConnection(dataSource.connection)
        )

        // Apply migrations
        assertDoesNotThrow {
            liquibase.update("test")
        }

        // Verify database state
        dataSource.connection.use { connection ->
            val statement = connection.createStatement()

            // Check if tables exist
            val tables = listOf("users", "roles", "user_roles")
            tables.forEach { table ->
                val resultSet = statement.executeQuery(
                    "SELECT COUNT(*) FROM information_schema.tables WHERE table_name = '$table'"
                )
                resultSet.next()
                assertEquals(1, resultSet.getInt(1), "Table $table should exist")
            }

            // Check if indexes exist
            val indexes = listOf("idx_users_email", "idx_users_active_department")
            indexes.forEach { index ->
                val resultSet = statement.executeQuery(
                    "SELECT COUNT(*) FROM pg_indexes WHERE indexname = '$index'"
                )
                resultSet.next()
                assertEquals(1, resultSet.getInt(1), "Index $index should exist")
            }
        }
    }

    @Test
    fun `should rollback migration successfully`() {
        val liquibase = LiquibaseFactory().createLiquibase(
            "db/changelog/db.changelog-master.xml",
            ClassLoaderResourceAccessor(),
            JdbcConnection(dataSource.connection)
        )

        // Apply migrations
        liquibase.update("test")

        // Count applied changesets
        val changesets = liquibase.listUnrunChangeSets("test", null)
        val appliedCount = liquibase.databaseChangeLog.changeSets.size - changesets.size

        // Rollback last changeset
        assertDoesNotThrow {
            liquibase.rollback(1, "test")
        }

        // Verify rollback
        val changesetsAfterRollback = liquibase.listUnrunChangeSets("test", null)
        assertEquals(changesets.size + 1, changesetsAfterRollback.size)
    }
}

Production Best Practices

1. Pre-deployment Validation

@Component
class MigrationValidator {

    fun validateMigrations(changelogFile: String): ValidationResult {
        val issues = mutableListOf<String>()

        // Parse changelog
        val changeLog = ChangeLogParserFactory.getInstance()
            .getParser(changelogFile, ClassLoaderResourceAccessor())
            .parse(changelogFile, ChangeLogParameters(), ClassLoaderResourceAccessor())

        changeLog.changeSets.forEach { changeSet ->
            // Check for risky operations
            changeSet.changes.forEach { change ->
                when (change) {
                    is DropTableChange ->
                        issues.add("Risky operation: DROP TABLE in ${changeSet.id}")
                    is DropColumnChange ->
                        issues.add("Risky operation: DROP COLUMN in ${changeSet.id}")
                    is AddNotNullConstraintChange -> {
                        if (change.defaultNullValue == null) {
                            issues.add("ADD NOT NULL without default value in ${changeSet.id}")
                        }
                    }
                }
            }

            // Check for rollback
            if (changeSet.rollback.changes.isEmpty()) {
                issues.add("No rollback defined for ${changeSet.id}")
            }
        }

        return ValidationResult(issues)
    }
}

data class ValidationResult(
    val issues: List<String>
) {
    val isValid: Boolean = issues.isEmpty()
}

2. Monitoring Migration Status

@RestController
@RequestMapping("/api/admin/migrations")
class MigrationController(
    private val liquibase: Liquibase
) {

    @GetMapping("/status")
    fun getMigrationStatus(): MigrationStatusResponse {
        val unrunChangeSets = liquibase.listUnrunChangeSets(null, null)
        val history = liquibase.ranChangeSetList

        return MigrationStatusResponse(
            totalChangesets = liquibase.databaseChangeLog.changeSets.size,
            appliedChangesets = history.size,
            pendingChangesets = unrunChangeSets.size,
            lastAppliedChangeset = history.lastOrNull()?.let {
                ChangesetInfo(it.id, it.author, it.dateExecuted)
            }
        )
    }

    @PostMapping("/validate")
    fun validatePendingMigrations(): ValidationResponse {
        val unrunChangeSets = liquibase.listUnrunChangeSets(null, null)
        val issues = mutableListOf<String>()

        unrunChangeSets.forEach { changeSet ->
            // Validate each pending changeset
            if (changeSet.rollback.changes.isEmpty()) {
                issues.add("No rollback for changeset: ${changeSet.id}")
            }
        }

        return ValidationResponse(
            valid = issues.isEmpty(),
            issues = issues
        )
    }
}

3. Backup Strategy

@Service
class DatabaseBackupService {

    private val logger = LoggerFactory.getLogger(DatabaseBackupService::class.java)

    @EventListener
    fun createBackupBeforeMigration(event: MigrationStartedEvent) {
        logger.info("Creating database backup before migration")

        val timestamp = LocalDateTime.now().format(DateTimeFormatter.ofPattern("yyyyMMdd_HHmmss"))
        val backupFile = "backup_before_migration_${timestamp}.sql"

        try {
            createDatabaseDump(backupFile)
            logger.info("Database backup created: {}", backupFile)
        } catch (e: Exception) {
            logger.error("Failed to create database backup", e)
            throw MigrationException("Backup failed", e)
        }
    }

    private fun createDatabaseDump(filename: String) {
        val processBuilder = ProcessBuilder(
            "pg_dump",
            "--host=${databaseHost}",
            "--port=${databasePort}",
            "--username=${databaseUsername}",
            "--dbname=${databaseName}",
            "--file=${filename}",
            "--verbose"
        )

        processBuilder.environment()["PGPASSWORD"] = databasePassword

        val process = processBuilder.start()
        val exitCode = process.waitFor()

        if (exitCode != 0) {
            throw RuntimeException("pg_dump failed with exit code: $exitCode")
        }
    }
}

Troubleshooting Common Issues

1. Changeset Checksum Mismatches

@Component
class ChecksumRepairService {

    fun repairChecksums(changesetId: String) {
        // This should be used carefully and only in development
        liquibase.clearCheckSums()
        logger.warn("Cleared checksums - database may be inconsistent")
    }

    fun validateChecksums(): List<String> {
        val issues = mutableListOf<String>()

        try {
            liquibase.validate()
        } catch (e: ValidationFailedException) {
            e.failedValidations.forEach { validation ->
                issues.add("Validation failed: ${validation.errorMessage}")
            }
        }

        return issues
    }
}

2. Failed Migration Recovery

-- Manual recovery queries (use with extreme caution)

-- Check current migration status
SELECT * FROM databasechangelog ORDER BY dateexecuted DESC LIMIT 10;

-- Mark changeset as executed (if it was partially applied)
INSERT INTO databasechangelog (id, author, filename, dateexecuted, orderexecuted, exectype, md5sum, description, comments, tag, liquibase)
VALUES ('changeset-id', 'author', 'changelog.xml', NOW(), 999, 'EXECUTED', 'checksum', 'Description', 'Comments', NULL, 'version');

-- Remove failed changeset record
DELETE FROM databasechangelog WHERE id = 'failed-changeset-id';

Conclusion

Liquibase provides a robust foundation for managing database schema evolution in Spring Boot applications. By following these practices, you can:

  • Maintain database schema consistency across environments
  • Track and version all database changes
  • Collaborate effectively with team members
  • Handle complex data migrations safely
  • Rollback problematic changes when needed

Key takeaways:

  • Always include rollback instructions in your changesets
  • Use contexts to separate environment-specific changes
  • Test migrations thoroughly before production deployment
  • Validate pending migrations before applying them
  • Create backups before major migrations
  • Monitor migration status in production

Start with simple migrations and gradually adopt more advanced patterns as your application grows. The investment in proper database migration management will save you countless hours of debugging and data recovery in production.

Ready to implement Liquibase? Start by setting up the basic configuration and creating your first migration. Remember to always test your migrations in a development environment before applying them to production.

Share this article

🐦 X 💼 LinkedIn 📘 Facebook

Get more insights delivered to your inbox

Join the discussion

Comments coming soon...
